Endcaped Φ2mm Quartz block at the end face of fiber is a good and low cost solution for decrease laser  power density, so that protect the fiber surface.

On the surface of the end cap, a high damage threshold AR coating is coated, while on the other side of the  fiber, a high efficient cladding power stripper (CPS) is built, most important it's Epoxy uncoupled part of light which injected into cladding.

Product Application:

• The output of fiber laser

• Fiber coupled Laser Diode

• Output end of laser machining

Product  Features:

• High reliability of splicing point.

• Epoxy-free CPS integrated on the power delivery fiber

• High burning threshold of AR coating

Ordering information

• Please descript the product and applicaiton like below

• 200/240 0.22NA fiber, 2mm endcaped fiber input, and SMA905 or D80 output, 600W, total 5m length (Cable  4m+ bare fiber 1m)

• Make a call or send email to sales@lasfiberio.comfor further assistance, thank you.
